Bulk pricing available for quantities of 2 units or more
Suits Zoom 2-piston callipers on Kaabo models of Mantis Pro & Wolf Warrior X/11/GT/GTR, Dragon Slayer and early model Lightning/Beast, later VSETT and hydraulic equipped Zero.
In stock: 89 available
1
Buy more, save more
Quantity
Price per item
Discount
2 items
AU$10.45
18% off
6 items
AU$7.73
39% off
10 items
AU$5.91
54% off
20 items
AU$5.00
61% off
Save this product for later
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
The non-finned NUTT pad (from factory Zero NUTT calliper)
The "Crown" pad, which will pretty much fit in any calliper of rectangular shape near this width.
Note the variance between first two and last three with respect to:
the shape of pad (pad placement / contact surface engagement area to the rotor).
distance from the hole to bottom of pad surface.
The Zoom full hydraulic calliper requires a pad that is slightly narrower than the Shimano BN01S/M315 pad which appears identical, however there is typically 0.5mm difference in width.
In order to fit into the Zoom calliper, the pad needs to not exceed width of 30.1mm. As a general rule, only the specific Zoom branded, retail packaged pads provide assurance of the pad being within that 30.1mm tolerance. The pad compound is organic resin semi-metal and this is the only type produced by Zoom. If you want to run alternative compounds, you will need to shave down approximately 0.4mm on each side to reduce the width of the plate (hand file is sufficient) on the Shimano B01S/M315 size pad. To further understand merits of each compound, refer to the Brake Pads Category homepage.
Image below shows contrast of this pad with slightly wider Shimano BN01S/M315 pad, which cannot fit in the calliper.
This image from an AliExpress seller shows various Zoom branded pads, suggesting this pad is DB-03 designation, although compatible callipers has no relation Zoom callipers on eScooters. The callipers DB680 and DB330/331 are all cable brake systems.
Here are some photos of inappropriate "Crown" shaped pads pulled out of a Zoom calliper in a Wolf Warrior King GT Calliper after 1000kms. It is not recommended to this pad in Zoom callipers, it is too short. The "Crown" Pad is often described as suitable for VSETT 10+ (Ride Electric) and suitable for VSETT and other Zoom models (Bike Scooter City). While the crown will fit, it is shallower than the Zoom which may result in only part of the pad surface engaging to the disc rotor, impacting performance and longevity. This is explained further on the Crown pad product page. There are a lot of pads out there in the field that aren't appropriate and don't assume the pad in your scooter is the correct one - check yours!!!
You can appreciate the outcome of prolonged use of inappropriate pad, as shown below on NAMI Burn-E 2 (Non-Max with Logan 2-piston calliper). Again, the Crown pads, this calliper should be fitted with Shimano B01S/M315.
Videos showing how to change pads on the Zoom calliper, here on VSETT 10+
