Main Cable suit Display/Throttle Dragon GTR/GTS inc V2 & Cyclone (JST SM 6-pin) [JP]

• Connects display/throttle to to controller on JST models of Dragon GTR, GTS, GTR V2, GTS V2, Cyclone and Cyclone Pro (Australia, Langfeite OEM).
• This variant has flat black 6-pin JST SM male plug on both ends. Wired for plug-and-play installation. Not suitable for the newer models as they adopt JST XH connector (with a Black Junction Box).
• Observed length: 1920mm (1.92 meters), excluding length of crimped connectors.
• Typically required as replacement when original main cable has been physically damaged or worn, which may cause errors on display or prevent operation.
• JP Factory Spare (Jipin), as adopted in these Dragon branded models.

Notes:

1. Refer to the controller page for wiring diagrams etc.
2. To remove the existing cable from the stem without cutting, de-pin the black JST SM connector once the order of colours have been noted. The wires can be removed from connector housing by using a SIM card removal pin (or similar shaped object) as shown in this video.
