NAMI Logan 2-Piston Brake Calliper (Burn-e 2 non-Max, Klima, Super Stellar & Blast)

• The NAMI Logan 2-Piston Brake Calliper (Burn-e 2 non-Max, Klima, Super Stellar & Blast) is the factory stock calliper on Burn-e 2 (non-Max model), all Klima (except SE), Super Stellar and all Blast (except the 72V variant of Blast Max). It supersedes the 2-piston NUTT calliper that was on the inaugural Burn-e (non 2 model).
• NAMI adopts "left" orientation, that is the hydraulic line extends from the left of calliper housing as observed looking at the side of the eScooter.

• Includes factory-fitted pads, pre-blead BH59 hydraulic line (hose) with barb/needle insert fitted and an IS mounting bracket:
  • Front (short): 1.28 meters length with bracket F-180 R-160 (bracket type on Burn-e and Klima).
  • Rear (long:) 2.1 meters length with bracket F-160 R-140 (bracket type on Klima, re-use existing taller F-180 R-160 for Burn-e).
• Optional Brake Lever Termination Kits:
  • Olive (bushing only): Copper coloured, compresses to form seal, single use.
  • 5PC kit: Olive plus metal compression nut, cover (hood/boot) as shown (as two sets) below & pair M6x18 bolts (to secure IS bracket to swing arm bracket).


• Typically required when replacement is needed such as hydraulic failure or leak.
• Genuine NAMI Factory Spare.

Notes:

1. Calliper uses Rectangular Brake Pad (31.5mm Shimano B01S/M315), secured with split pin.
2. Typically paired with Logan levers.
3. Supports rotors to and including 3mm width.
4. NAMI Super Stellar has shorter length hydraulic line (hose). Cut to length and refit/insert the barb/needle or run service loop.
5. eSN also stocks a range of TurboBrake callipers, which are also offered in "rights".
