TurboTap NFC Bypass Switch for NAMI

• eScootNow's TurboTap NFC Bypass Switch for NAMI is an elementary, factory prepared cable with switch that performs the Power-ON/OFF function that is traditionally performed by the NFC reader.
• Designed for plug-and-play fitting on NAMI makes including Burn-e, Blast & Klima. Adopts a female M8 3-pin yellow connector using the same wiring configuration as that of the NAMI NFC reader.
• Can be used as a direct replacement to the NFC reader, or co-reside with the reader for concurrent operation via an optional M8 Y Splitter (1xF-2xM).
• The physical switch is often considered more "convenient" for casual use than needing to constantly swipe cards to power on and off the eScooter. The inline switch can be mounted somewhat discrete underneath the handlebar or unplugged for a higher security posture. Many riders choose to have one "on hand" in event of NFC failure.
• Available as:
  • Inline sealed which is waterproof and secure, all ready to go as shown in green.
  • Inline unsealed (shown in red) is without application of black 704 silicon adhesive glue in grommets at each end. The later is slightly lower cost and allows you to inspect or reconfigure the design before sealing the cable grommet.
  • Handlebar Mount Sealed (not shown), was expected Q3 2026 as part of ESN2026#JP-CN launch offerings, deferred to the TurboTap Aux Switch project Q1 2027.


• The red 2-pin male M8 connector provides a power outlet to run additional headlight, TurboTorch Headlights and TurboTap products. The output is live when the eScooter is powered on (either by the switch itself or the NFC card reader). The outlet is not switched by the Light and Horn Switch. The switch can be opened to change power outlet to be live 24/7 (+ve from battery) if desired as terminals are soldered pins with screw type terminations - serviceable with screwdriver. It can also be converted to 24/7 by simply fitting inline a TurboTap Throttle Conversion Cable between this switch and the main line as that cable changes the power source from Power-ON to Always on.

Notes:

1. Inline variant released November 2024. Handlebar mounted variant expected Q2 2026 as part of eSN2026#JP-CN.
2. Can be disconnected from main line (or y splitter) in event the switch needs to be disabled to fall back purely on NFC reader.
3. If the red M8 2-pin male Auxiliary Power Power Output is not to be used, ensure the supplied cap/cover remains fitted and secured with adhesive. The output is identical to that of the NAMI headlight, being M8 2-pin red. The output can be used, for example, to plug-and-play aftermarket headlights such as TurboTorch Cobra and BushMaster that are fitted with the NAMI headlight M8 2-pin red connector.


4. Co-design and peer reviewed by Michael Sha, NAMI - Ningbo, China. Wire colours adopted match that of NAMI Main Line.
5. This product may be adopted by scooters that adopt a male plug on the NFC reader. Models adopting this include Teverun and Blade/TNE models including Bolzzen Commando 4818 + 4823. Image below shows inclusion of a 3 Pin Yellow Male-Male 6cm cable to convert the polarity. This implementation reverses polarity on the red 2-pin output as the 6cm cable is "straight through" or could be corrected with Throttle Conversion Cable.
