NAMI Swing Arm for Motor (suit Klima)

• Swing Arm's for Motors on NAMI Klima are produced in two variants, "Left" and "Right" which is the designation of the front swing arm:
  • Left (for motor wire):
    • Has provision for motor cable protection plate with 5mm unthreaded hole in casting.
    • Motor mounts on the left end of the arm as viewed from the side.
    • Suits front left hand side or rear right hand side.
  • Right (for brake calliper):
    • Has provision for mounting the brake bracket and calliper with two 5mm unthreaded holes in casting.
    • Motor mounts on the right end of the arm as viewed from the side.
    • Suits front right hand side or rear left hand side.
• Both arms have:
  • 12mm unthreaded hole on one end of the casting to directly accommodate the shaft for swing arm.
  • 10mm opening at the other end for the key on the motor axil shaft.
  • Two M5 threaded holes in casting for mounting of the plastic fender.
  • An 8mm unthreaded hole in casting with observed depth of 32mm to directly accommodate the Suspension Shaft for Bottom, 120mm.

• Typically required when replacement is needed from physical damage such as front end collision or similar significant impact. Often renewed as part of heavy maintenance if the suspension shaft holes have deformed resulting in play in suspension. The arms are relatively light weight at 386 / 410 grams respectively and use relatively small 8mm suspension shafts which results in reduced strength than heavier arms, such as those on Burn-e.
• Genuine NAMI Factory Spare.

Notes:

1. Be cautions if using internet images as reference, note the first image below of the older tail light model from the far side of the stand is inverted (the photo is flipped left/right). The second image with the newer Tail Light with Extended Fender is rendered appropriately, from the stand side.


2. Ensure the hole in casting for the suspension shaft is clean before fitting the shaft.
